BB1131
CHANGXING
Horizontal engineer wood block slicing machine
1 Double V-chutes are used for both sides the machine, with high parallel; special polymer wear-resistant material coated on the surface.Machine runs in higher stability and with less friction.
2 Serve motor control system is used for timber feeding, guarantees the veneer thickness in a high precision, avoiding blade scratch on the timber
3 Whole casted beam holds the log stongly, and hydraulic driven hooks clamp the log tightly and effectively. Vacuum disc system is used inside the log beam to help holding the big timber in order to avoid logs deforming or dropping down during cutting procedure
4 All switch button are gathered in a cabinet.Single person can operate the machine avoiding the dangerous caused by fault
5 Special designed big size driving gear runs smoothly with a low noie when it runs in a high speed
| SPECIFICATIONS FOR HORIZONTAL VENEER SLICER | |||
| Model | BB1131 | BB1226 | BB1142 |
| Max cutting size | 2600x700x680mm | 2600x1300x950mm | 4200x1300x950mm |
| Blade size | 3500x200x24mm | 3500x200x24mm | 4500x2000x24mm |
| Veneer thickness | 0.1-2.2mm | 0.1-2.2mm | 0.1-2.2mm |
| Cutting speed | 0-36pcs/min | 0-36pcs/min | 0-36pcs/min |
| Wood clamping unit | 10units | 10 units | 10units |
| Clamping methods | Hydraulic | Hydraulic | Hydraulic |
| Total weight | 22Tons | 24Tons | 32Tons |
| Overall size | 8030x4530x2530mm | 9530x5670x2470mm | 9550x5950x2990mm |
Cell/Whatsapp:+86 13695390052
